Napoleon Fireplaces GDS 50-N - Manual (Page 2)

2
W415-0098 / C / 04.19.06
Pg 2-4 INTRODUCTION
Warranty
General Instructions
General Information
Care of Glass & Plated Parts
5 LOCATION & CLEARANCES
6-11 DIRECT VENT SPECIFICS
MODEL GDS50
Vent Lengths/Air Terminal Locations
Special Installation Example
Offset Installation Example
Wall & Ceiling Protection
Horizontal Venting Installation
Vertical Venting Installation
Stove Vent Connection
Mobile Home Installation
12-14 B-VENT SPECIFICS
MODEL GS50
Chimney Installation
'B' Vent Installation
Adding Vent Sections
Flashing and Storm Collar Installation
'B' Vent Adaptations
Combustion Air
Pg 14 GAS INSTALLATION
15-16 FINISHING
Door Opening & Closing
Louvre & Trivet Installation
Mantle Clearances
Log Placement
17-18 OPERATION / MAINTENANCE
Spill Switch
Turbo Burner
Operating Instructions
Maintenance
19 REPLACEMENT BLOWER
20 ADJUSTMENTS
Pilot Burner Adjustment
Venturi Adjustments
21-22 REPLACEMENTS
Ordering Replacement Parts
Terminal Kits
Accessories
Replacement Parts
23-24 TROUBLE SHOOTING GUIDE
TABLE of CONTENTS
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
W A R N I N G W A R N I N G W A R N I N G W A R N I N G W A R N I N G
• The stove is a vented gas-fired heater. Do not burn wood or other materials in this stove.
• Adults and especially children should be alerted to the hazards of high surface temperatures and should stay
away to avoid burns or clothing ignition. Supervise young children when they are in the same room as the stove.
• Due to high temperatures, the stove should be located out of traffic and away from furniture and draperies.
• Clothing or other flammable material should not be placed on or near the stove.
• Any safety screen or guard removed for servicing must be replaced prior to operating the stove.
• It is imperative that the control compartments, burners and circulating blower and its passageway in the stove
and venting system are kept clean. The stove and its venting system should be inspected before use and at least
annually by a qualified service person. More frequent cleaning may be required due to excessive lint from
carpeting, bedding material, etc. The stove area must be kept clear and free from combustible materials, gaso
line and other flammable vapours and liquids.
• Under no circumstances should this stove be modified.
• This stove must not be connected to a chimney flue pipe serving a separate solid fuel burning appliance.
• Do not use this stove if any part has been under water. Immediately call a qualified service technician to inspect
the stove and to replace any part of the control system and any gas control which has been under water.
• Do not operate the stove with the glass door opened, cracked or broken. Replacement of the glass should be done
by a licensed or qualified service person.
• Do not strike or slam shut the stove glass door.
• This fireplace uses and requires a fast acting thermocouple. Replace only with a fast acting thermocouple
supplied by Wolf Steel Ltd.
• Adults and especially children should be alerted to the hazards of high surface temperatures and should stay
away to avoid burns or clothing ignition. Keep young children and animals away when the fireplace is hot.
