Making the Physical Connections 2-5
Netopia 4622 T1 Router Status Lights
The figure below represents the Netopia 4622 status light (LED) panel.
Netopia 4622 LED front panel
The following table summarizes the meaning of the various LED states and colors:
When this happens... the LEDs...
The power is on Power is green.
The Router detects an error Alert is red.
The WAN has trained WAN is green.
An Ethernet por t is connected to an Ethernet link par tner
device The corresponding Ethernet light is solid
green.
An Ethernet por t has activity The corresponding Ethernet light flashes
green.
Note: The remaining LEDs are not used.
POWER
W
AN
Ethernet
ALERT
