Nortec Industries NHTC Series User Manual
Page 30
10-30
Page 3
2008-02-18
Figure 1. OnLine Diagnostic LED Locations
Figure 2. BACnet Module LED
Figure 3. LonWorks Module LED
Figure 4. Ethernet Port
Module
Status
Serial
Port
Activity
Ethernet
Activity
Ethernet
Link
RX – Receive LED
TX – Transmit LED
Power LED
Ethernet
LINKS 2
Ethernet
Activity
Lon Device Status
RX –
Receive LED
TX –
Transmit LED
Power LED
