© National Instruments Corporation 3-1 VXI-SC-1102/B/C User Manual
Chapter
3
Signal Connections
This chapter describes the analog input signal connections to the
VXI-SC-1102/B/C submodule via the front connector.
Caution: Static electricity is a major cause of component failure. To prevent damage
to the electrical components in the module, observe antistatic techniques
whenever removing a module from the chassis or whenever working on a
module.
Front Connector
Figure 3-1 shows the pin assignments for the VXI-SC-1102/B/C
submodule front connector.
!
