K E Y P AD C O N T R O L S & I N D I C AT O R S

Window. Displays system status

messages, zone descriptions, etc.

STATUS Light. Lights (green) to
indicate that the system is ready
for arming. If a zone is not
secured the light will be off and
the zone will display in the
window. If a zone has been
bypassed, the STATUS light will
blink while armed.

ARMED Light. Lights (red) to

indicate that the system is armed.
If an alarm has occurred, the
ARMED LED will be flashing.

FUNCTION Button. Selects

available system functions as
displayed in the window. The
selected function is executed by
pressing the

Jto button.

BYPASS Button. (1) Deactivates
selected zones from the system.
(2) Unbypasses a bypassed zone

(GEM-P3200/9600 panels only)

RESET Button. (1) Resets

various system troubles, displays,
etc. (See text.) (2) Resets
residential smoke detectors.

Numerical Keys (1-9, 0). Used to

enter codes, zone numbers, etc.

ON/OFF Button. Entry key.

Causes the entered code or
selected function to be executed.

INTERIOR Button. (1) Bypasses
all Interior Zones simultaneously
to allow free movement within the
premises. (2) Scrolls the window
display forward (NEXT). (3)
Answers “YES” to questions in
the window display.

INSTANT Button. (1) Cancels

entry delay on Exit/Entry Zones,
causing an instant alarm upon
violation. (2) Scrolls window
display backward (PRIOR). (3)
Answers “NO” to questions in the
window display.

AREA Button (*). Selects other

are as and is use d with
emergency buttons.

Emergency Buttons. Used with

the

button to signal an

emergency, as follows:

Press the

and the

buttons for Fire Emergency.

Press the

and the

buttons for Auxiliary Emergency.

Press the

and the

buttons for Police Emergency.
