Blue Sky Network August 07
6 D3000 100458
D3000 OVERVIEW
Specifications
Length 7.87” or 200 mm (9” or 228mm with ICB)
Width 3.22” or 82 mm (5” or 127mm with ICB)
Depth 1.5” or 38 mm (2.5” or 64mm with ICB)
Weight 1.1lb or 0.5Kg (2.0 lb or 0.9Kg with ICB)
Power Requirements 9VDC - 18VDC
Nominal Current 0.5A Continuous, 1.0A Peak at 12V
Operating Temperature Range -20 degrees C to + 70 degrees C
Iridium SBD Frequency L-Band
GPS Frequency L-Band
LED Indicator Power (ON/OFF)
I/O Ports 2 Serial Ports (RS-232)
Antenna Dual terminal GPS/Iridium combined
Features
Worldwide - The D3000 is a truly global satellite communication solution, based on the
Iridium satellite network.
GPS - The D3000 has an integrated GPS. Users can define position reporting intervals
via the unit, locally or remotely.
Asset Tracking - Directly from our web-portal, SkyRouter (www.blueskynetwork.com),
users can view the location of one or a fleet of mobile assets. Tracking data can also be
utilized by third party tracking solutions, like Integraph’s.
2-Way Messaging – The D3000 allows users to send and receive messages between
vehicles or between dispatch and vehicle.
