9
1. Make sure that the power cord is unplugged.
Remove the indicated Screw (7) and the Access
Door (95) from the left side of the Console Base
(98).
2. Connect the wire on the receiver (A) to the indi-
cated wire extending from the Console Base
(98). Hold the receiver so the small cylinder is
oriented as shown and is facing the Console
Base. Attach the receiver to the plastic posts on
the Access Door (95) with the two included small
screws.
3. Make sure that no wires are pinched.
Reattach the Access Door (95) with the Screw
(7). Discard the other wires included with the re-
ceiver.
If you purchase the optional chest pulse sensor (see page 20), follow the steps below to install the re-
ceiver included with the chest pulse sensor.
A
98
Small
Cylinder 7
95
Wire
Small
Screws
