Navini Networks, Inc. PMX User’s Guide
Installing NavDiag,
continued
Troubleshooting
Using Navini
Diagnostics
Step Action
Illustration
13. The Installing screen
will change as the
application files are
loaded.
Windows 2000 Screen
14. At the Install Complete
screen, click Done to
close the window.
Windows 2000 Screen
To open the Navini Diagnostics software application, double-click
on the Navini Diagnostics icon on your desktop.
The Connection Status screen will open and display data if the
PMX is in use. The screen will refresh live data every second.
