Speed accuracy

±1.5%

Wow and flutter

<0.1% JIS weighted, RMS
<0.2% DIN weighted, peak

Frequency response

40Hz - 15kHz ±3dB

MPX filter response

Flat within 1dB to 15kHz

Harmonic distortion

<0.3% at -10dB

THD at 0dB

Normal tape

<1%

CrO

, Metal

<2%

Signal/Noise ratio

Dolby off

53dB

Dolby B

63dB

Dolby C

73dB

Channel separation

35dB broadband

Erasure

>65dB at 1kHz

Input sensitivity

60mV

Input impedance

8.2k

Ω

Maximum input level

10V

Output level at 0dB

380mV

Output impedance

4.7k

Ω

Remote

NAD Link

PHYSICAL SPECIFICATIONS
Dimensions (W x H x D)

420 x 127 x 229mm

Net weight

3.4kg

Shipping weight

4.2kg

Dimensions are of unit’s cabinet without attached feet; add up to 18mm for total height.

Dimension depth excludes terminals, sockets, controls and buttons.
