23
Electrifi ed Direct Connect Inlets
Electrifi ed Inlets make it a simple one-step operation to plug in a
Current-Carrying hose – no 120V extension cord to carry around.
Compatible with NuTone CH615 and CH620 hoses.
CI390 Standard and CI395 Status Indicating
The ElectraValve ® Electrifi ed Inlet operates on standard house wiring.
It eliminates the need for the extension of electrical cords from the inlet
to an electrical outlet. The molded power receptacle clips to a mounting
plate and the housing wire is run to the nearest outlet box.
• UL listed Assembly
• Standard:
CI390W – White CI390V – Ivory
• Status Indicating:
CI395W – White CI395V – Ivory
CI395RK Rough-In Kit
The Electrifi ed Inlet Rough-In Kit includes everything you need to
install the CI390 and CI395 inlets. Includes mounting plate, snap-
in power receptacle, 6' of 12-gauge cable assembly, plaster guard,
CF382S elbow and mounting screws for plaster guard.
CI358 Supervalves
The Supervalve Electrifi ed Inlet operates on standard house wiring.
Includes wall valve, rough-in plate with junction box and strain relief.
• UL listed assembly
CI358W – White CI358IV – Ivory
CI390V
CI358W
HOW TO CHOOSE:
CI390 CI395 CI358 CI370 CI335 360 330 CI398
Current Carr
ying
CH620 • • •
*CH520 • • • • •
CH615 or VXCH615 • • •
*CH515 or *VXCH515 • • • • •
Lo
w
Volt
age
372 ° ° ° ° °
CH235 or VXCH235 ° ° ° ° °
CH230 ° ° ° ° °
Utility
*CH310 x x x x x
CH115 ° ° ° ° °
* Includes 6 ft. line cord ° Limited Function (suction only/non-powered)
• Full Function x Limited Function (powered only/no switch)
Hose
Type
Inlet Type
