NEC XM37 User Manual
Page 30
12
50
49
Maximum Resolution
RGB 1024( H) X
768(V) pixels
VIDEO Horizontal: 500 lines /S-VIDEO Horizontal : 600 lines
Video Bandwidth
RGB: 70 MHz at-3dB
VIDEO: 5 MHz at-3dB
Display Area
RGB : 95% Scan (Typically)
VIDEO: 7% Overscan
Retrace Time
Horizontal: 15.75kHz: 7.0
µ
sec, 30kHz µ sec, 51kHz µ sec, 81kHz µ sec Vertical: 0.4 msec Current Rating AC 100-120 V/220-240 V, 50/60 Hz Power Consumption XP37 Plus(XP-3790): 4.5 A (maximum) / XM37 Plus(XM-3760): 4.5A (maximum) Dimensions 872(W) x 744(H) x 590(D) mm / 34.4(W) x 29.3(H) x 23.3(D) inches Weight 103.5 kg / 228.2 lbs Environmental Considerations Operating Temperature : 0 to 40 Humidity : 0 to 90% Altitude : 0 to 10,000 feet Storage Temperature : -10 to 50 Humidity : 0 to 95% Altitude : 0 to 45,000 feet Regulations : UL Approved (UL 1950, CSA 950) Meets DOC Canada requirements Meets FCC class A requirements Meets DHHS requirements Meets RED ACT All specifications are subject to change without notice.
