Distortion
Timebase System
Reference clock...................................... 10 MHz
Clock accuracy (as master) .................... 10 MHz ±50 ppm
1 MS/s
400 kHz
–160 dBfs/
–104 dBfs
500 kS/s
200 kHz
–160 dBfs/
–107 dBfs
200 kS/s
80 kHz
–160 dBfs/
–111 dBfs
100 kS/s
40 kHz
–160 dBfs/
–114 dBfs
50 kS/s
20 kHz
–160 dBfs/
–117 dBfs
20 kS/s
8 kHz
–160 dBfs/
–121 dBfs
10 kS/s
4 kHz
–160 dBfs/
–124 dBfs
* 1 32 in oscilloscope mode Sampling Frequency SFDR for input 0 dBfs SFDR for input –20 dBfs SFDR for input –60 dBfs (typical) 100 MS/s 50 dB 50 dB N/A 12.5 MS/s 65 dB 85 dB 125 dB 5 MS/s 70 dB 90 dB 130 dB 2.5 MS/s 75 dB 95 dB 135 dB 1 MS/s 85 dB 105 dB 145 dB 500 kS/s 90 dB 110 dB 150 dB 200 kS/s 100 dB 110 dB 160 dB 100 kS/s 100 dB 110 dB 160 dB 50 kS/s 100 dB 110 dB 160 dB 20 kS/s 100 dB 110 dB 160 dB 10 kS/s 100 dB 110 dB 160 dB Sampling Frequency Bandwidth Noise Density Total Noise Hz Hz Hz Hz Hz Hz Hz
