The Modular Shelf puts an end to the
problem of storing taller items and wasted
space. This unique design maximizes
capacity with six modular half-shelves
that can be positioned in a variety of
configurations. Shelves can be adjusted
without tools to accommodate a broad
variety of container shapes and sizes.

Here’s a design that’s worth a second look.
The Pan door’s design covers the normal
gap between the cabinet body and the
door with a unique flange. It’s the perfect
complement to the clean polished edge of
the polished mirror. Reversible for left- or
right-hand installation, the Pan door also
features three adjustable shelves and a
magnetic closure.

Modular Shelf

Shown: modular Shelf 468mOD

Flush Mount Cabinet

Pan Door

Shown: Flush mount

Cabinet 869P24WHG

Shown: Pan Door
935P24WH

The Flush Mount does exactly
that—mounts flush to the wall
surface to provide an ultra clean
presentation. With the door
surface just 1/2" off the wall
surface, you’ll hardly know it’s
there. Concealed European hinges
swing the door open with a gentle
push on the spring loaded touch-
latch to reveal three adjustable
shelves.

model

Frame

Door

mirror

Overall Size

Wall Opening

Number

Type

Type

Shape

w

h

d

w

h

d

Flush mount Cabinet

recessed mount

869P24WH

Frameless

Single

Rectangle

15 26

4

1

2

14 24

4

870P24WH

Frameless

Single

Rectangle

15 26

4

1

2

14 24

4

870P34WH

Frameless

Single

Rectangle

15 36

4

1

2

14 34

4

869P24WHG

Frameless

Single

Rectangle

15 26

4

1

2

14 24

4

869P34WHG

Frameless

Single

Rectangle

15 36

4

1

2

14 34

4

870P24WHG

Frameless

Single

Rectangle

15 26

4

1

2

14 24

4

870P34WHG

Frameless

Single

Rectangle

15 36

4

1

2

14 34

4

modular Shelf

recessed mount

468MOD

Stainless

Single

Rectangle

16 26

4

1

2

14 24 3

1

2

Pan Door

recessed mount

935P24WH

Frameless

Single

Rectangle

16 26

5

14 24 3

1

2

935P34WH

Frameless

Single

Rectangle

16 36

5

14 34 3

1

2

Note: All measurements are in inches.
Stainless = Stainless steel.
