F r A m e l e S S C A B i N e T S
‑
Simple, clean polished-edge design enables this
tri-view mirror with built-in top lights to complement
a wide range of decorating styles.
Focus
20
Shown: Focus 295230 and Focus 1430 (inset)
Beveled-edge elegance with a rounded corner
design makes the Quantum tri-view ideal for use
with any decorative motif.
Quantum
Shown: Quantum 455248
model Frame Door mirror Overall Size Wall Opening
Number Type Type Shape w h d w h d
Focus recessed mount
1430 Frameless Single Rectangle 16 22 4 3 ⁄
4
14 18 3 1 ⁄
2
1433* Frameless Single Rectangle 16 3 ⁄
16
20 3 ⁄
16
— 14 18 2 1 ⁄
2
1438 Frameless Single Rectangle 16 26 4 1 ⁄
2
14 24 3 1 ⁄
2
B7733* Frameless Single Rectangle 16 26 3 5 ⁄
8
14 24 3 1 ⁄
2
B7233* Frameless Single Rectangle 16 22 4 13 1 ⁄
2
17 1 ⁄
2
3
835P24WHD Frameless Single Rectangle 16 26 4 1 ⁄
2
14 24 3 1 ⁄
2
835P24WHG Frameless Single Rectangle 16 26 4 1 ⁄
2
14 24 3 1 ⁄
2
835P34WHD Frameless Single Rectangle 16 36 4 1 ⁄
2
14 34 3 1 ⁄
2
835P34WHG Frameless Single Rectangle 16 36 4 1 ⁄
2
14 34 3 1 ⁄
2
Focus Surface mount with Built-in Top lights
295224 n Frameless Tri-View Rectangle 24 30 5 1 ⁄
4
295230 n Frameless Tri-View Rectangle 30 34 5 1 ⁄
4
Quantum Surface mount with Built-in Top lights
455230 n Frameless Tri-View Rectangle 30 36 1 ⁄
2
5 1 ⁄
4
455236 n Frameless Tri-View Rectangle 36 36 1 ⁄
2
5 1 ⁄
2
455248 n Frameless Tri-View Rectangle 48 36 1 ⁄
2
5 1 ⁄
2
B885393 n Frameless Tri-View Rectangle 24 33 4 1 ⁄
2
Note: All measurements are in inches. n Cabinet depth does NOT include light bulbs or the socket.
* Molded body.
