S31NUK5120(3)2001-04
BRAKES ADJUSTMENT
When the pedal brake and/or the parking brake
reach a low efficiency operation some
adjustments can be done on the front wheel
(models SR 1100 e SR 5110):
- loosen the locking nut A
- turn adjuster B
- tighten locking nut A.
On models SR 1200 and SR 5120 the two
brakes on the rear wheels can also be adjusted,
by means of the regulating devices located
under the foot board (under the brake pedal).
FRONT LAMP REPLACEMENT
In order to replace the front lamp:
- remove the transparent cover
- push the lamp and turn it counter-clockwise to
remove it
- replace the lamp paying attention to the volt
and watt ratings
- fit the transparent cover.
MAINTENANCE
20
B
A
