Installation Guide for Gigabit TX/SX Tap
Specifications
Splitter Specifications:
Split.Ratio:.50/50
Fiber.Type:.Multimode.Corning.62 .5/125µm,.wavelength.850nm
Insertion Loss: Network Port: ≤ 4.5 dB
Monitor Port: ≤ 4.5 dB
Operating Specifications:
Operating Temperature: 10˚C to 55˚C
Storage Temperature: 0˚C to 70˚C
Relative.Humidity:.10%.min,.95%.max,.non-condensing
Mechanical Specifications:
Power Supply: Input: 100-240 VAC, 47-63 Hz, 0.5A
(AC100-125V, 50-60Hz, 30VA for Japan)
Output: 12V, 1.5A (5V, 2.4A for UK and Japan)
Dimensions: 1.125" high x 6.5" deep x 4.5” wide
Connectors:
(1) Duplex SC connector (monitoring port)
(2) RJ45, 8 pin connectors (network ports)
Cable Interface:
Copper Cable Type: 22-24 AWG unshielded twisted pair cable, CAT5E
Fiber Optic Interface:
Laser:.Class.I,.eye-safe,.laser.emitter.type ..These.Class.I.Lasers.conform.
to the applicable requirements per US 21 CFR (J) and EN 60825-1, also
UL.1950.applications .
Optical.Transmitter.Wave.Length:.850.nm.nominal.
Output Power: -9.5 dB min, -4.0 dB max
Optical.Receiver.Input.Sensitivity:..0.dB.min,.-17.dB.max
