Cordless Internet Phone with Skype Model SPH200D User Manual
1-8 Getting Started
v1.0, November 2006
Base Unit
The following table describes the keys and connectors on the base unit.
Figure 1-4
Table 1-4. Base Unit Keys and Connectors
Indicators, Buttons, and
Connectors
Description
Skype line indicator • Blinks when receiving a Skype line call.
• Lit when the Skype line is in use.
Landline indicator Blinks when receiving a landline call.
Page button • Find handsets.
• Register handsets.
Reset button • Push and release to reset the power.
• Push and hold for 5 seconds, and then release to reset to
factory default settings.
Telephone (landline) jack Connect to the landline.
Ethernet jack Connect to the Internet.
Power connector Connect to the power adapter.
Page button
Skype line indicator
Landline indicator
Reset button
Telephone (landline) jack
Power connector
Ethernet connector
