11
5. Technical Specification
This section provides the specifications of the 3-slot Gigabit Chassis switch and the
following table lists these specifications.
Standard
IEEE802.3 10Base-T
IEEE802.3u 100Base-TX
IEEE802.3z Gigabit fiber
IEEE802.3ab 1000Base-T
Switch architecture Store and forward switch architecture
LED Indicators
System: Power
Per RJ-45 port: 1000/100Mbps, Link/Activity, Full
duplex/ collision
Gigabit SX/LX/MINI GBIC slot: Link/Activity
Connector
Gigabit copper: RJ-45 with Auto MID/MDI-X
Gigabit Fiber: SC
MINI GBIC: LC (3.3 V type)
Transfer Rate
14880 Packets per Second for 10Mbps
148800 Packets per second for 100Mbps
1488000 Packets per second for 1000Mbps
Network Cable
10Base-T: 2 pairs UTP/STP CAT.3, 4, 5 cable
EIA/TIA 568 100Ohm(100M)
100Base-TX: 2 pairs UTP/STP CAT. 5 cable EIA/TIA
568 100Ohm(100M)
Gigabit Copper: 4 pairs UTP/STP CAT. 5 or CAT. 5e
