Ⅲ Press the DUAL
button to turn the passenger’s side temperature controls on or
off. This will allow the passenger’s side temperature to be adjusted independently
from the driver’s side control.
Ⅲ When AUTO is pressed, AUTO will be displayed. When DUAL is pressed, DUAL
will be displayed.
DRIVER’S SIDE TEMPERATURE CONTROL DIAL/AUTO MODE
Turn the driver’s temperature control dial left for cold air or right for hot air.
PASSENGER’S SIDE TEMPERATURE CONTROL DIAL/DUAL MODE
Turn the passenger’s temperature control dial left for cold air or right for hot air. Doing so
will activate dual mode.
AIR FLOW/MODE BUTTON
Press the MODE button repeatedly to select the following air flow outlets:
Air flows from the center and side vents.
Air flows from the center, side, and foot vents.
Air flows mainly from the foot vent.
Air flows from the defroster and foot vents.
Air flows mainly from the defroster vents.
FAN SPEED CONTROL BUTTONS
Press (slower) or (faster) button to control fan speed. Press AUTO to
automatically control fan speed. Press OFF to turn the climate control off.
DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS
Ⅲ Press the defroster control button
to turn the system on. The A/C automatically
turns on when the defroster mode is selected.
Ⅲ Turn the driver’s side temperature control dial
left or right to set the desired
temperature.
Ⅲ To set the defroster on high, press and hold the
button until fan speed
increases.
DEFROSTING/DEFOGGING REAR WINDOW AND OUTSIDE HEATED MIR-
ROR (if so equipped).
Push the rear window defroster switch on. Push the switch again to manually turn
the defroster off. This function automatically turns off in approximately 15 minutes.
