5
Optical Bypass Switch
Unpacking and Inspection
Unpack.the.Optical.Bypass.Switch,.power.supply,.and.cables.provided ..Each.
Optical.Bypass.Switch.is.delivered.with.the.following:
For models N-IDP-POBPSX-001, N-IDP-POBPLX-002:
•..1.DC.power.supply
• 2 Duplex SC-SC fiber cables
• 2 Duplex SC-LC fiber cables
•..1.Manual
If.any.component.is.missing.or.damaged,.contact.Net.Optics.Customer.
Service.immediately .
Connecting the Optical Bypass Switch to the
Network
1 ..Connect.Network.Port.A.to.the.appropriate.switch,.server.or.router.device.
using a duplex SC fiber cable. This acts as your DCE interface.
2 ..Connect.Network.Port.B.to.the.appropriate.switch,.server.or.router.device.
using a duplex SC fiber cable. This acts as your DTE interface.
3 ..Verify.that.the.Bypass.Switch.Network.Ports.are.cabled.in-line.between.two.
devices .
