Optical Bypass Switch
Specifications
Splitter Specifications:
Fiber Type: Multimode:.Corning.62 .5/125µm,.wavelength,.850nm
Insertion Loss: Network Port: ≤ 1.25 dB
Monitor Port: ≤ 1.25 dB
Fiber Type: Singlemode:.Corning.8 .5/125µm,.wavelength,.1300nm
Insertion Loss: Network Port: ≤ 1.25 dB
Monitor Port: ≤ 1.25 dB
Note: There is no insertion loss when the switch is not receiving power
and is in Bypass Disabled mode.
Operating Specifications:
Operating Temperature: 5˚C to 40˚C
Storage Temperature: -10˚C to 70˚C
Relative.Humidity:.10%.min,.95%.max,.non-condensing
Mechanical Specifications:
Power.Supply:.Input.Power:.100-250V,.0 .5A,.47-63Hz
. .Output.Power:.5V,.2 .4A
Dimensions:.1 .125”.high.x.6 .0”.deep.x.6 .5”.wide
Connectors:
(2).Duplex.SC.connectors.(monitoring.ports)
(2).Duplex.SC.connectors.(network.ports)
