4. SUPPLIED ACCESSORIES
Description Designation Qty
Serial
No.
Remarks
Rangefinder
Tripod (optional)
Angular mount
(optional)
Rechargeable
battery
Fuse link VP1-1
1,0 A 250 V
Sealing ring
Framed lens
Membrane
Eye shield
Diaphragm
Pencil TM, M, CT, T
Wrench
Synthesized fiber
brush KXOOK No.
7
Coordinate converter
Cable
Cable
Cable
Cable
Cable AEP 41.46.712
G 42.14.067
G 42.21.812
10D-0,55С-1
G 68.79.193-
02
G 44.21.885
AEP 75.48.092
G 47.92.131
AEP 73.54.031
AEP 87.61.505
G 42.41.211
AEP 48.44.037
AEP 48.44.038
AEP 48.44.039
AEP 48.44.040
AEP 48.44.120 1
1
1
2
5
2
1
2
2
1
1
1
1
1
1
1
1
1
1
- protection device 12, used to supply the rangefinder with
(27±2.7) V DC or 22-29 V from a vehicle electrical system,
or with 22-29 V or 12-14.5 V from external batteries;
- cable 14, used to couple the protection device to the
electrical system of a track-laying vehicle;
- cable 15, used to connect the protection device to external
rechargeable battery type 6CT70 (or analogous);
- cable 16, used to connect the protection device or charging
device to the electrical system of a wheeled truck;
- cable 17, used to couple the charging device to a mains of
220 V 50 Hz;
- cable 18, used to couple the protection device to external
battery type 21NКBN-3,5;
- pencil 3 and eraser 8, used while working with the map and
coordinate converter;
- coordinate converter 10, used for polar-to-rectangular
coordinate conversion, reference location of the observation
post and orientation of the range finder;
- sealing ring 4, used to seal battery section;
- eye shield 5, used to exclude incident light in the eyepiece;
- framed lens 6, used to contribute the angle reading
convenience and accuracy when operating the AI;
- membrane 19 to seal the MEASURE button assembly;
- cover 20, to protect the rangefinder against direct sun rays;
- cover 21, used to protect the rechargeable battery against
damages.
