NEC Display Solutions

500 Park Boulevard, Suite 1100

Itasca, IL 60143

866-NEC-MORE

AccuSync PV32

32”

0.5108mm

500 cd/m

2

5000:1 (Dynamic)

178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10

Rapid Response (6ms grey-to-grey)

256 RGB Level, more than 16.7 million

Manual

76 x 45 cm / 29.9 x 17.7 in.

16:9

56 - 68.7 kHz

50 - 85 Hz

ANALOG 0.7 Vp-p/75 Ohms

Separate sync: TTL Level (Positive/Negative)

Composite sync: TTL Level (Positive/Negative)

Composite sync on green: (0.3Vp-p negative 0.7Vp-p

positive)

Analog D-Sub

HDMI w/ HDCP (2)

Composite RCA (3)

S-Video

Component BNC (2)

PC Audio

NTSC-M (Latin: NTSC-M, PAL-M, PAL-N), ATSC

RS-232C

No

Composite RCA

Headphone, RCA, SPDIF

15W + 15W

720 x 400 @ 70-85 Hz

640 x 480 @ 60-85 Hz

800 x 600 @ 56-85 Hz

1024 x 768 @ 60-85 Hz

1280 x 1024 @ 60 Hz

1280 x 768 @ 60-75 Hz

1360 x 768 @ 60 Hz

NTSC, HDTV, 480p, 576p, 720p, 1080i

1366 x 768

1366 x 768

English, French, Spanish and Portugese

3-D comb filter, 5-mode picture status memory,

detachable speakers (15W + 15W), 4-mode

color status memory, sound status memory, digital

smooth, digital control, swivel, VESA mount, Om-

niColor (NCM), sharpness/softness, off-timer, 10-bit

gamma, running hours, AutoBright (signal input),

color temperature mode, auto DVI selection, swivel

stand, RGB delay compensations, PIP/POP, V-Chip,

aspect ratio converter, still image, child lock

AC 100-120 V / AC 200-240 V @ 50/60 Hz

Internal

130W

<5W

31.7 x 25.4 x 9.3 in. / 806 x 644 x 235mm

31.7 x 23.5 x 4.5 in. / 806 x 597 x 114mm

44.1 lbs / 20 kg

41.1 lbs / 18.6 kg

200 x 200mm

0-40°C / 32-104°F

0-80%

4000m / 13,123 ft.

0-60°C / -4-140°F

0-90%

10,000m / 32,808 ft.

UL/C-UL or CSA, FCC CLASS B/CANADIAN DOC

AC power cord, user manual, 15-pin RGB (VGA)

cable, warranty card

Tilting wall mount

2 years parts and labor, including backlight

M - F (7am - 7pm CST)

AccuSync PV40

40”

0.648mm

500 cd/m

2

5000:1 (Dynamic)

178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10

Rapid Response (6ms grey-to-grey)

256 RGB Level, more than 16.7 million

Manual

95.2 x 55.10 cm / 37.5 x 21.7 in.

16:9

56 - 68.7 kHz

50 - 85 Hz

ANALOG 0.7 Vp-p/75 Ohms

Separate sync: TTL Level (Positive/Negative)

Composite sync: TTL Level (Positive/Negative)

Composite sync on green: (0.3Vp-p negative 0.7Vp-p

positive)

Analog D-Sub

HDMI w/ HDCP (3)

Composite RCA (3)

S-Video

Component BNC (2)

PC Audio

NTSC-M (Latin: NTSC-M, PAL-M, PAL-N), ATSC

RS-232C

No

Composite RCA

Headphone, RCA, SPDIF

20W + 20W

720 x 400 @ 70-85 Hz

640 x 480 @ 60-85 Hz

800 x 600 @ 56-85 Hz

1024 x 768 @ 60-85 Hz

1280 x 1024 @ 60 Hz

1280 x 768 @ 60-75 Hz

1360 x 768 @ 60 Hz

NTSC, HDTV, 480p, 576p, 720p, 1080i

1366 x 768

1366 x 768

English, French, Spanish and Portugese

3-D comb filter, 5-mode picture status memory,

detachable speakers (20W + 20W), 4-mode

color status memory, sound status memory, digital

smooth, digital control, swivel, VESA mount, Om-

niColor (NCM), sharpness/softness, off-timer, 10-bit

gamma, running hours, AutoBright (signal input),

color temperature mode, auto DVI selection, swivel

stand, RGB delay compensations, PIP/POP, V-Chip,

aspect ratio converter, still image, child lock

AC 100-120 V / AC 200-240 V @ 50/60 Hz

Internal

205W

<5W

39.3 x 29.4 x 11.7 in. / 998 x 748 x 298mm

39.3 x 27.5 x 4.8 in. / 998 x 698 x 121.2mm

52.1 lbs / 23.6 kg

48.1 lbs / 21.8 kg

200 x 200mm

0-40°C / 32-104°F

0-80%

4000m / 13,123 ft.

0-60°C / -4-140°F

0-90%

10,000m / 32,808 ft.

UL/C-UL or CSA, FCC CLASS B/CANADIAN DOC

AC power cord, user manual, 15-pin RGB (VGA)

cable, warranty card

Tilting wall mount

2 years parts and labor, including backlight

M - F (7am - 7pm CST)

AccuSync PV46

46”

0.7455mm

500 cd/m

2

5000:1 (Dynamic)

178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10

Rapid Response (6ms grey-to-grey)

256 RGB Level, more than 16.7 million

Manual

76 x 45 cm / 29.9 x 17.7 in.

16:9

56 - 68.7 kHz

50 - 85 Hz

ANALOG 0.7 Vp-p/75 Ohms

Separate sync: TTL Level (Positive/Negative)

Composite sync: TTL Level (Positive/Negative)

Composite sync on green: (0.3Vp-p negative 0.7Vp-p

positive)

Analog D-Sub

HDMI w/ HDCP (3)

Composite RCA (3)

S-Video

Component BNC (2)

PC Audio

NTSC-M (Latin: NTSC-M, PAL-M, PAL-N), ATSC

RS-232C

No

Composite RCA

Headphone, RCA, SPDIF

20W + 20W

720 x 400 @ 70-85 Hz

640 x 480 @ 60-85 Hz

800 x 600 @ 56-85 Hz

1024 x 768 @ 60-85 Hz

1280 x 1024 @ 60 Hz

1280 x 768 @ 60-75 Hz

1360 x 768 @ 60 Hz

NTSC, HDTV, 480p, 576p, 720p, 1080i

1366 x 768

1366 x 768

English, French, Spanish and Portugese

3-D comb filter, 5-mode picture status memory,

detachable speakers (20W + 20W), 4-mode

color status memory, sound status memory, digital

smooth, digital control, swivel, OmniColor (NCM),

sharpness/softness, off-timer, 10-bit gamma, running

hours, AutoBright (signal input), color temperature

mode, auto DVI selection, swivel stand, RGB delay

compensations, PIP/POP, V-Chip, aspect ratio

converter, still image, child lock

AC 100-120 V / AC 200-240 V @ 50/60 Hz

Internal

260W

<5W

45 x 33 x 14 in. / 1142 x 937 x 355mm

45 x 31.1 x 4.8 in. / 1142 x 789 x 121.4mm

85.1 lbs / 38.6 kg

80.1 lbs / 36.3 kg

688 x 216mm

0-40°C / 32-104°F

0-80%

4000 m / 13,123 ft.

0-60°C / -4-140°F

0-90%

10,000m / 32,808 ft.

UL/C-UL or CSA, FCC CLASS B/CANADIAN DOC

AC power cord, user manual, 15-pin RGB (VGA)

cable, warranty card

Tilting wall mount

1 year parts and labor, including backlight

M - F (7am - 7pm CST)
