Newcon Optik NV66-G2 User Manual
Page 20
16
5.10 Using optional helmet mount
The unit can be equipped with an optional helmet mount.
This mount can be customized to fit a variety of existing
helmet models.
The mount is attached to a helmet with straps.
1 - Locking screw
3 - Flip/Flop
adjusting screws
2 - Flip/Flop button
4 - Mount binding
screw
1 2
3
4
Fig.6 NV66-G2 with 8x lens
