NEC MultiSync 70 Series Specifications

Model

Display:

Viewable Image Size
Pixel Pitch
Pixels Per Inch
Brightness (typical)
Contrast Ratio (typical)
Viewing Angle (typical)

Response Time (typical)
Display Colors

Synchronization Range:

Horizontal

Vertical

Input Signal:

Video
Sync

Inputs

Resolutions Supported

Native Resolution

Additional Features

Voltage Rating

Power Consumption (typical):

On
Power Savings Mode

Net Dimensions (WxHxD):

(with stand)

(without stand)

Net Weight

(with stand)
(without stand)

VESA Hole Configuration
Specifications

Environmental Conditions:

Operating Temperature
Operating Humidity
Operating Altitude
Storage Temperature
Storage Humidity
Storage Altitude

Limited Warranty

Technical Support

500 Park Boulevard, Suite 1100
Itasca, Illinois 60143
866-NEC-MORE
www.necdisplay.com

NEC Display Solutions

MultiSync LCD1570NX

15"
0.297mm
85.5 @ native resolution
250 cd/m2
450:1
140 Vert., 160 Hor.
(60U/80D/80L/80R)(CR>5)
Rapid Response (16ms)
More than 16 million

31.5-60 kHz (Analog)
31.5-60 kHz (Digital)
56-75 Hz

ANALOG 0.7 Vp-p / 75 Ohms
Separate sync: TTL Level
(Positive/Negative)
Composite sync: TTL Level
(Positive/Negative)
Composite sync on green:
(0.3 Vp-p negative 0.7 Vp-p
positive)

DVI-D and VGA 15 pin D-sub

ANALOG/ DIGITAL
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz

1024 x 768 @ 75 Hz

Thin-frame (bezel), No
Touch Auto Adjust, NaViSet
software, sRGB, AccuColor
color control, digital
smoothing, digital controls,
Plug and Play (VESA DDC
1/2B), VESA DPMS power
management, OSM user
controls, ISO 13406-2 Class
II, vacation switch, height-
adjustable stand, Ambix

AC 100-120V/AC 220-240V

20W
<2W

13.2 x 12-15 x 7 in/
336.4 x 305-380 x 178mm

13.2 x 10.3 x 2.2 in/
336.4 x 261.9 x 56mm

8.4 lbs/3.8 kg
6.2 lbs/2.8 kg

75mm x 75mm

5-35°C/41-95°F
30-80%
3,048 m/10,000 ft
-10-60°C/14-140°F
10-85%
12,192 m/40,000 ft

3 years parts and labor,
including backlight

24 hours/7 days

MultiSync LCD1770VX

17"
0.264mm
96.2 @ native resolution
250 cd/m2
600:1
160 Vert., 160 Hor.
(85U/75D/80L/80R)(CR>5)
Rapid Response (8ms)
More than 16 million

31.5-81 kHz (Analog)
31.5-69 kHz (Digital)
56-75 Hz

ANALOG 0.7 Vp-p / 75 Ohms
Separate sync: TTL Level
(Positive/Negative)
Composite sync: TTL Level
(Positive/Negative)
Composite sync on green:
(0.3 Vp-p negative 0.7 Vp-p
positive)

DVI-D and VGA 15 pin D-sub

ANALOG/ DIGITAL
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 70-75 Hz
1280 x 960 @ 60-75 Hz
1280 x 1024 @ 60-76 Hz

1280 x 1024 @ 60 Hz

Thin-frame (bezel), No
Touch Auto Adjust, NaViSet
software, sRGB, AccuColor
color control, digital
smoothing, digital controls,
Plug and Play (VESA DDC
1/2B), VESA DPMS power
management, OSM user
controls, ISO 13406-2 Class
II, vacation switch, height-
adjustable stand, Ambix

AC 100-120V/AC 220-240V

36W
<2W

14.4 x 14.3-18.6 x 7.8 in/
367 x 362.5-472.5 x 198mm

14.4 x 12.5 x 2.3 in/
367 x 317 x 59.5mm

13.2 lbs/6 kg
9.3 lbs/4.2 kg

100mm x 100mm

5-35°C/41-95°F
10-80%
3,048 m/10,000 ft
-20-60°C/4-140°F
5-85%
16,000 m/52,493 ft

3 years parts and labor,
including backlight

24 hours/7 days

MultiSync LCD1770NXM

17"
0.264mm
96.2 @ native resolution
250 cd/m2
600:1
160 Vert., 160 Hor.
(85U/75D/80L/80R)(CR>5)
Rapid Response (8ms)
More than 16 million

31.5-81 kHz (Analog)
31.5-69 kHz (Digital)
56-75 Hz

ANALOG 0.7 Vp-p / 75 Ohms
Separate sync: TTL Level
(Positive/Negative)
Composite sync: TTL Level
(Positive/Negative)
Composite sync on green:
(0.3 Vp-p negative 0.7 Vp-p
positive)

DVI-D and VGA 15 pin D-sub

ANALOG/ DIGITAL
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 70-75 Hz
1152 x 870 @ 75 Hz
1280 x 1024 @ 60-75 Hz

1280 x 1024 @ 60 Hz

Thin-frame (bezel),
Soundbar 70, No Touch
Auto Adjust, NaViSet
software, USB 2.0, sRGB,
AccuColor color control,
bezel-integrated speakers,
digital smoothing, digital
controls, Plug and Play
(VESA DDC 1/2B), VESA DPMS
power management, OSM
user controls, ISO 13406-2
Class II, Ambix

AC 100-120V/AC 220-240V

55W
<2W

14.4 x 14.5-18.6 x 7.8 in/
367 x 368.6-472.5 x 198mm

14.4 x 13.7 x 2.3 in/
367 x 347.6 x 59.5mm

14.3 lbs/6.5 kg
10.4 lbs/4.7 kg

100mm x 100mm

5-35°C/41-95°F
10-80%
3,048 m/10,000 ft
-20-60°C/4-140°F
5-95%
16,000 m/52,493 ft

3 years parts and labor,
including backlight

24 hours/7 days

MultiSync LCD1770NX

17"
0.264mm
96.2 @ native resolution
250 cd/m2
600:1
160 Vert., 160 Hor.
(85U/75D/80L/80R)(CR>5)
Rapid Response (8ms)
More than 16 million

31.5-81 kHz (Analog)
31.5-69 kHz (Digital)
56-75 Hz

ANALOG 0.7 Vp-p / 75 Ohms
Separate sync: TTL Level
(Positive/Negative)
Composite sync: TTL Level
(Positive/Negative)
Composite sync on green:
(0.3 Vp-p negative 0.7 Vp-p
positive)

DVI-D and VGA 15 pin D-sub

ANALOG/ DIGITAL
720 x 400 @ 70 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 70-75 Hz
1152 x 870 @ 75 Hz
1280 x 1024 @ 60-75 Hz

1280 x 1024 @ 60 Hz

Thin-frame (bezel), No
Touch Auto Adjust, NaViSet
software, USB 2.0, sRGB,
AccuColor color control,
digital smoothing, digital
controls, Plug and Play
(VESA DDC 1/2B), VESA DPMS
power management, OSM
user controls, ISO 13406-2
Class II, vacation switch,
height-adjustable stand,
Ambix

AC 100-120V/AC 220-240V

48W
<2W

14.4 x 14.3-18.6 x 7.8 in/
367 x 362.5-472.5 x 198mm

14.4 x 12.5 x 2.3 in/
367 x 317 x 59.5mm

13.4 lbs/6.1 kg
9.5 lbs/4.3 kg

100mm x 100mm

5-35°C/41-95°F
10-80%
3,048 m/10,000 ft
-20-60°C/4-140°F
5-95%
16,000 m/52,493 ft

3 years parts and labor,
including backlight

24 hours/7 days

MultiSync LCD1970VX

19"
0.294mm
86 @ native resolution
270 cd/m2
550:1
145 Vert., 160 Hor.
(75U/70D/80L/80R) (CR>5)
Rapid Response (8ms)
More than 16 million

31.5-81.1 kHz (Analog)
31.5-81.1 kHz (Digital)
56-75 Hz

ANALOG 0.7 Vp-p / 75 Ohms
Separate sync: TTL Level
(Positive/Negative)

DVI-D and VGA 15 pin D-sub

ANALOG/ DIGITAL
720 x 400 @ 70-75 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 75 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60 Hz
1280 x 1024 @ 60-75 Hz

1280 x 1024 @ 60 Hz

Thin-frame (bezel), No
Touch Auto Adjust, NaViSet
software, sRGB, AccuColor
color control, digital
smoothing, digital controls,
Plug and Play (VESA DDC
1/2B), VESA DPMS power
management, OSM user
controls, ISO 13406-2 Class
II, vacation switch, height-
adjustable stand, Ambix

AC 100-120V/AC 220-240V

36W
<2W

16.2 x 15.2-19.5 x 8.7 in/
412.5 x 386.5-496.5 x
220mm
16.2 x 13.7 x 2.6 in/
412.5 x 347.5 x 66mm

15.4 lbs/7 kg
10.8 lbs/4.9 kg

100mm x 100mm

5-35°C/41-95°F
30-80%
3,048 m/10,000 ft
-10-60°C/14-140°F
10-85%
9,144 m/30,000 ft

3 years parts and labor,
including backlight

24 hours/7 days

MultiSync LCD1970NX

19"
0.294mm
86 @ native resolution
250 cd/m2
800:1
176 Vert., 176 Hor.
(88U/88D/88L/88R)(CR>10)
Rapid Response (18ms)
More than 16 million

31.5-81.1 kHz (Analog)
31.5-81.1 kHz (Digital)
56-75 Hz

ANALOG 0.7 Vp-p / 75 Ohms
Separate sync: TTL Level
(Positive/Negative)
Composite sync: TTL Level
(Positive/Negative)
Composite sync on green:
(0.3 Vp-p negative 0.7 Vp-p
positive)

DVI-D and VGA 15 pin D-sub

ANALOG/ DIGITAL
720 x 400 @ 70-75 Hz
640 x 480 @ 60-75 Hz
800 x 600 @ 56-75 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-75 Hz
1152 x 864 @ 75 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 60 Hz
1280 x 1024 @ 60-75 Hz

1280 x 1024 @ 60 Hz

Thin-frame (bezel), No
Touch Auto Adjust, NaViSet
software, USB 2.0, sRGB,
AccuColor color control,
digital smoothing, digital
controls, Plug and Play
(VESA DDC 1/2B), VESA DPMS
power management, OSM
user controls, ISO 13406-2
Class II, vacation switch,
height-adjustable stand,
XtraView, Ambix

AC 100-120V/AC 220-240V

52W
<2W

16.2 x 15.2-19.5 x 8.7 in/
412.5 x 386.5-496.5 x
220mm
16.2 x 13.7 x 2.6 in/
412.5 x 347.5 x 66mm

16.5 lbs/7.5 kg
11.9 lbs/5.4 kg

100mm x 100mm

5-35°C/41-95°F
30-80%
3,048 m/10,000 ft
-10-60°C/14-140°F
10-85%
12,192 m/40,000 ft

3 years parts and labor,
including backlight

24 hours/7 days

MultiSync LCD2070NX

20.1"
0.255mm
100 @ native resolution
250 cd/m2
400:1
176 Vert., 176 Hor.
(88U/88D/88L/88R)(CR>10)
Rapid Response (16ms)
More than 16 million

31.5-91.1 kHz (Analog)
31.5-91.1 kHz (Digital)
56-85 Hz

ANALOG 0.7 Vp-p / 75 Ohms
Separate sync: TTL Level
(Positive/Negative)
Composite sync: TTL Level
(Positive/Negative)
Composite sync on green:
(0.3 Vp-p negative 0.7 Vp-p
positive)


DVI-D and VGA 15 pin D-sub

ANALOG/ DIGITAL
720 x 400 @ 85 Hz
640 x 480 @ 60-85 Hz
800 x 600 @ 56-85 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-85 Hz
1152 x 864 @ 75 Hz
1152 x 870 @ 75 Hz
1280 x 1024 @ 60-85 Hz
1600 x 1200 @ 60 Hz

1600 x 1200 @ 60 Hz

Thin-frame (bezel), No
Touch Auto Adjust, NaViSet
software, USB 2.0, sRGB,
AccuColor color control,
digital smoothing, digital
controls, Plug and Play
(VESA DDC 1/2B), VESA DPMS
power management, OSM
user controls, ISO 13406-2
Class II, vacation switch,
height-adjustable stand,
XtraView, Ambix

AC 100-120V/AC 220-240V

74W
<3W

17.4 x 15.3-19.6 x 8.7 in/
442 x 388.5-498.5 x 220mm

17.4 x 13.4 x 2.8 in/
442 x 340 x 72mm

19 lbs/8.6 kg
12.6 lbs/5.7 kg

100mm x 100mm

5-35°C/41-95°F
30-80%
3,658 m/12,000 ft
-10-60°C/14-140°F
10-85%
12,192 m/40,000 ft

3 years parts and labor,
including backlight

24 hours/7 days

MultiSync LCD2170NX

21.3"
0.270mm
94 @ native resolution
300 cd/m2
1000:1
176 Vert., 176 Hor.
(88U/88D/88L/88R) (CR>10)
Rapid Response (8ms G-to-G)
More than 16 million


31.5-91.1 kHz (Analog)
31.5-91.1 kHz (Digital)
56-85 Hz

ANALOG 0.7 Vp-p / 75 Ohms

Separate sync: TTL Level
(Positive/Negative)
Composite sync: TTL Level
(Positive/Negative)
Composite sync on green:
(0.3 Vp-p negative 0.7 Vp-p
positive)


DVI-D and VGA 15 pin D-sub

ANALOG/ DIGITAL
720 x 400 @ 85 Hz
640 x 480 @ 60-85 Hz
800 x 600 @ 56-85 Hz
832 x 624 @ 75 Hz
1024 x 768 @ 60-85 Hz
1152 x 864 @ 85 Hz
1152 x 870 @ 75 Hz
1280 x 960 @ 75Hz
1280 x 1024 @ 60-85 Hz
1600 x 1200 @ 60 Hz

1600 x 1200 @ 60 Hz

Thin-frame (bezel), No
Touch Auto Adjust, NaViSet
software, USB 2.0, sRGB,
AccuColor color control,
digital smoothing, digital
controls, Plug and Play
(VESA DDC 1/2B), VESA DPMS
power management, OSM
user controls, ISO 13406-2
Class II, vacation switch,
height-adjustable stand,
XtraView, Ambix

AC 100-120V/AC 220-240V

66W
<2W

18.3 x 15.6-20 x 8.7 in/
466 x 397.7-507.7 x 220mm

18.3 x 14.3 x 2.8 in/
466 x 362 x 71mm

20.3 lbs/9.2 kg
14.1 lbs/6.4 kg

100mm x 100mm

5-35°C/41-95°F
30-80%
3,658 m/12,000 ft
-10-60°C/14-140°F
10-85%
12,192 m/40,000 ft

3 years parts and labor,
including backlight

24 hours / 7 days
