Niles Audio RS5 - Manual (Page 19)

SPECIFIC
A
TIONS
18
SPECIFICATIONS
Recommended Amplifier Power
10 to 100 Watts
Nominal Impedance
8 Ohms
Frequency Response
70 Hz to 20 kHz
Sensitivity
90 decibels for 2.83 Volts RMS of Pink Noise, measured at 1 Meter on Axis
Wiring Requirements
2-conductor direct burial cable at the following sizes depending on longest
length of cable required:
Wire Gauge Maximum Distance
16 . . . . . . . . . . . .60 ft (18 m)
14 . . . . . . . . . . . .100 ft (30 m)
12 . . . . . . . . . . . .160 ft (50 m)
Temperature Extremes
-50° to 185° Fahrenheit
-45° to 85° Celsius
Dimensions
10" Length x 8-1/2" Deep x 9-1/2" High
254mm Length x 216mm Deep x 241mm High
Weight (Loudspeaker Only)
11.5 lbs.
5.2 kgs.
