Nikon 35mm User Manual
Page 35
- 35 -
Setting the SCSI ID on the Internal Scanner
The SCSI ID is set by a set of DIP switches on the back of the
internal-mount scanner as shown below. In most cases, these
DIP switches will not be changed.
If it is necessary to change the default SCSI ID, change the
position of the DIP switches to the proper SCSI ID. Refer to
Table 5.2 for the proper DIP switch values. When changing the
position of the switches, use a pointed instrument to toggle the
switch. Use of a pen or pencil is not recommended, since these
will leave a mark on the switch and make it difficult to
differentiate between the “on” and “off” positions.
SCSI ID
DIP #1
DIP #2
DIP #3
0
Open
Open
Open
1
Closed
Open
Open
2
Open
Closed
Open
3
Closed
Closed
Open
4
Open
Open
Closed
5
Closed
Open
Closed
6
Open
Closed
Closed
7
Closed
Closed
Closed
Table 5.2 SCSI ID DIP switch values
Factory default for
COOLSCAN II
