Napoleon Fireplaces TUREEN GD82PT-T - Manual (Page 27)

27
W415-0583 / D / 07.24.07
# PART NO. DESCRIPTION
1 W135-0275 OUTER ROCKS
2 W135-0304 SINGLE ROCK
3 W135-0277 BOWL
4 GL-655 ROCK SET ASSEMBLY
5 W565-0090 WIRE MESH
6* W390-0002 DOOR LATCH ( EA )
7 W725-0047 NATURAL GAS VALVE - MODULATING
7 W725-0048 PROPANE GAS VALVE - MODULATING
8* W455-0019 NATURAL GAS ORIFICE #43
8* W455-0003 PROPANE GAS ORIFICE #54
9 W680-0005 THERMOCOUPLE **
10 W240-0005 ELECTRODE C / W LEAD
11 W680-0004 THERMOPILE
12 W010- 1194 NATURAL GAS PILOT ASSEMBLY
13 W010- 1201 PROPANE GAS PILOT ASSEMBLY
14* W455-0070 NG PILOT INJECTOR
14* W455-0068 LP PILOT INJECTOR
15* W385-0334 NAPOLEON® LOGO
16 W500-0106 FIRESTOP (2 INCH CLEARANCE)
17 W100-0099 BURNER
18 GD 552 BLOWER
19 W660-0041 SPARK SWITCH
20 W660-0046 TRANSMITTER
21 W660-0045 RECEIVER
22 W190-0017 DC SPARK UNIT CONTROL
23 W300-0086 NIGHT LIGHT GLASS
24 W387-0006 NIGHT LIGHT LAMP
25 W750-0107 NIGHT LIGHT WIRE
26 W290-0080 NIGHT LIGHT LENSE GASKET
27* W361-0027 INSULATION SLEEVE
28 W225-0171 DOOR
29* W500-0205 RESTRICTOR
30* W010-1500 GLASS W/ GASKET
44* W573-0007 HI-TEMP SEALANT
45 GD501 HEAT GUARD
46 GA-566 HOT AIR DISTRIBUTION KIT
47* GA-72 HOT AIR EXHAUST KIT
48 GA-70 EXTENSION KIT, 5FT FLEX VENT
49* W010-0370 WALL SUPPORT ASSEMBLY
50* W175-0001 4” COUPLER
51* W175-0013 7” COUPLER
52* W175-0239 CONVERSION KIT - NG TO LP
53* W175-0240 CONVERSION KIT - LP TO NG
54 RFK82 RECTANGLE FACING KIT
55 AFK82 ARCHED FACING KIT
56* RFK82WI WROUGHT IRON FACING KIT
Contact your dealer for questions concerning prices and avail-
ability of replacement parts. Normally all parts can be ordered
through your Napoleon® dealer or distributor.
When ordering replacement parts always give the following
information: 1. M ODEL & S ERIAL N UMBER OF FIREPLACE
2. I NSTALLATION DATE OF FIREPLACE
3. P ART N UMBER
4. D ESCRIPTION OF PART
5. F INISH
FOR WARRANTY REPLACEMENT PARTS
,
A PHOTOCOPY OF
THE ORIGINAL INVOICE WILL BE REQUIRED TO HONOUR
THE CLAIM .
REPLACEMENTS
*
IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED
.
FOR
FURTHER INFORMATION
,
CONTACT YOUR
N
APOLEON
®
DEALER .
REPLACEMENT PARTS
ACCESSORIES
GD220 (5 FT)
31* W010-0397 4” FLEXIBLE ALUMINIUM LINER
- (5 FT ) C / W SPACERS
31* W410-0017 7” FLEXIBLE ALUMINIUM LINER - (5 FT )
GD330 (10 FT)
32* W010-0300 4” FLEXIBLE ALUMINIUM LINER
- (10 FT ) C / W SPACERS
32* W410-0018 7” FLEXIBLE ALUMINIUM LINER - (10 FT )
33* W010-0370 WALL SUPPORT ASSEMBLY
34 PERISCOPE - GD201
35 WALL TERMINAL KIT - GD222R
36* 1/12 TO 7/12 PITCH - GD110
37* 8/12 TO 12/12 PITCH - GD111
38* FLAT ROOF - GD112
39 W490-0073 4/7 INNER/OUTER SLEEVE
40 W670-0006 4/7 TERMINAL
41 W170-0086 STORM COLLAR
42 W010-0453 ROOF SUPPORT
43 W263-0065 / ROOF FLASHING
W263-0066 / ROOF FLASHING
W263-0067 ROOF FLASHING
FLEXIBLE VENT KITS
TERMINAL KITS
ROOF TERMINAL KITS
** WARNING: This is a fast acting thermocouple. It is an integral safety component. Replace only with a fast acting ther-
mocouple supplied by Wolf Steel Ltd.
NOTE: Care must be taken when removing and disposing of any broken glass or damaged components. Be sure to vacuum
up and broken glass from inside the fi replace before operation.
Installation and repairs must be performed by a qualifi ed installer, service agency or the supplier.
** WARNING: Failure to position the parts in accordance with these diagrams or failure to use only parts specifi cally approved
with this appliance may result in property damage or personal injury.
