Napoleon Fireplaces TUREEN GD82PT-T - Manual (Page 22)

22
W415-0583 / D / 07.24.07
ADDRESS SETTING PROCEDURE
Use the UP and DOWN key on the transmitter until the cursor
(small triangle) is left of the clock icon. From time 0:00 press
the LEFT key ten times. The display will show then the trans-
mitter address. Press the LEFT key to exit this function.
The transmitter address is required to be equal to the Re-
ceiver. (Fig. 55) Select, through setting of the dip switches,
the address of the receiver. (Fig. 57) Switch #8 must always
be in the ON position (down). It is also possible to start a
receiver address search sequence through the Transmitter.
To enter this function use the DOWN or UP keys until the
cursor (small triangle) is left of the clock icon. From time
0:00 press the LEFT key tem times. The display will then
show the present transmitter address. To alter the address
of the Transmitter press the UP key to increase and DOWN
to decrease it.
A “beep” from the Receiver will confi rm the same address as
the Transmitter. Press LEFT key to exit this function.
Note: The address of the Receiver is acquired only at its
power on. Changing the address while the Receiver is
powered will not have any effect. To change the address
of the Receiver, disconnect the power cable from the
Receiver, change the address and reconnect the power
cable to the Receiver.
FIGURE 55
FAHRENHEIT - Celsius Temperature Indication
It is possible to set the Remote Control to display the tempera-
tures in either Fahrenheit or Celsius. Use the UP or DOWN
key on the Transmitter until the cursor (small triangle) is left of
the click icon. From time 0:00 press the LEFT key ten times.
The display will show the transmitter address. Use the RIGHT
key to toggle from ºF to ºC and vice versa. The display will
show the selected unit of measure. Press the LEFT key to
exit this function. (Fig. 56)
FIGURE 56
