Wiring
From every IR Sensor location you must “home-run” a
category 5 cable back to the MSU250. Home run means that
an individual cable is connected between each IR Sensor and
the MSU250 (Figure 4).

6

I

N

F

R

A

R

E

D

M

A

I

N

S

Y

S

T

E

M

U

N

I

T

“TECH TIP”

Wire size is expressed
by it’s AWG (American

Wire Gauge) num-

ber. The lower the

AWG number, the

larger the wire, i.e.,

20 AWG wire is physi-

cally larger than

22 AWG.

IMPORTANT – AVOIDING INTERFERENCE

Avoid locating any of the cables, Sensors, Keypads or the
Main System Unit near any potential sources of Electro-
Magnetic Interference (EMI), such as light dimmers, speed
controls for ceiling fans, electrical ballasts, television sets,
large motors, heaters or air conditioners.

Figure 4: Home run the
sensor cable from the
sensor to the MSU250.
