OUTPUT TO MSU
POWER
STATUS
+12V DC
IRH610
IR EXPANSION HUB
INPUT 1
INPUT 4INPUT 5INPUT 6
INPUT 2
INPUT 3
12VDC
Power supply (Not Supplied)
plugged into a switched outlet
Niles stock# FG00060A
IRH610
Expansion Hub
MSU250
Main System Unit
Infrared
Sensors
Figure 9
Wiring diagram for
expanding a system
using the IRH610
Infrared Expansion Hub.
15
