12
W415-0559 / 02.15.06
Contact your dealer for questions concerning prices and
availability of replacement parts. Normally all parts can be
ordered through your Napoleon dealer or distributor.
When ordering replacement parts always give the following
information: 1. M ODEL & S ERIAL N UMBER OF FIREPLACE
2. I NSTALLATION DATE OF FIREPLACE
3. P ART N UMBER
4. D ESCRIPTION OF PART
5. F INISH
FOR WARRANTY REPLACEMENT PARTS , A PHOTOCOPY
OF THE ORIGINAL INVOICE WILL BE REQUIRED TO HON
-
OUR THE CLAIM
.
REPLACEMENTS
* IDENTIFIES ITEMS WHICH ARE NOT ILLUSTRATED . FOR
FURTHER INFORMATION , CONTACT YOUR NAPOLEON
DEALER .
# PART # DESCRIPTION
1 W135-0248 LOG #1- REAR
2 W135-0249 LOG #2 - LEFT
3 W135-0250 LOG #3 - RIGHT
4 GL-651 LOG SET
5 W725-0050 SIT VALVE - NG
5 W725-0031 SIT VALVE - LP
6 W100-0094 BURNER (NATURAL GAS)
6 W100-0094 BURNER (PROPANE)
7 W455-0019 #43 BURNER ORIFICE - NG
7 W455-0003 #54 BURNER ORIFICE - LP
10 W662-0001 NG OXYGEN DEPLETION SENSOR SYSTEM
10 W662-0005 LP OXYGEN DEPLETION SENSOR SYSTEM
12 W357-0001 PIEZO IGNITOR
11 W080-0756 PILOT BRACKET
13* W385-0245 NAPOLEON LOGO
14* W660-0009 ON/OFF SWITCH
15* W690-0002 THERMODISC
16 KB-35 VARIABLE SPEED SWITCH
17* GZ552 REPLACEMENT BLOWER
18 W135-0233 FRONT
19 W135-0232 SIDE (LEFT OR RIGHT)
20 W135-0231 TOP
21 W080-0757 BRACKET, COLLECTOR
22 W565-0087 SCREEN
23* W430-0013 CONTROL DOOR MAGNET
24 W010-1307 CONTROL COVER
25* W750-0149 PILOT LIGHT ASSEMBLY
26 W080-0755 BRACKET, THERMODISC EXTENSION
27* W690-0001 MILLIVOLT THERMOSTAT
28* W660-0010B REMOTE CONTROL
28* W660-0011B REMOTE CONTROL - ADVANTAGE PLUS
29 GS-65KT BLOWER KIT
30* GDSLL-KT LEG LEVELLING KIT
31* W175-0234 CONVERSION KIT - NG - LP
31* W175-0237 CONVERSION KIT - LP - NG
32* W175-0001 4" COUPLER
33* GS331S STOVE TOP INSET - SOAPSTONE
34* GS-331F STOVE TOP INSET - GRANITE - GREEN
35* GS-331N STOVE TOP INSET - GRANITE - BROWN
36* W660-0026 PROGRAMMABLE TIMER
REPLACEMENT PARTS
ACCESSORIES:
