North Star M165957K - Manual (Page 6)

Specifications
6
SPECIFICATIONS
Item Number 165957
Maximum Output 8000 Watts (W)
Continuous Output 6600 Watts (W)
Voltage 120 / 240 Volt (V)
Phase Single phase (4-wire)
Frequency 56.5-63.3 Hertz (Hz)
Power Factor 1.0 p.f.
Engine 13 HP Honda GX390
Engine Speed 3390-3800 RPM
Fuel Type Unleaded gasoline
Fuel Capacity 6.5 gallons (24.6 L)
Oil Capacity 1.16 US quarts (1.1 L)
Starting Method Electric / Recoil
120 V Receptacle 15 Amp (A) duplex
(NEMA 5-15R) & 20 Amp (A) duplex
(NEMA 5-20R)
120/240 V Receptacle 30 Amp (A) locking device
(NEMA L14-30R)
Circuit Breakers 30 Amp (A), Qty. 2; 20 Amp (A), Qty. 2;
15 Amp (A), Qty. 1; thermal,
push to reset style
Grounding Post Receives 12 Ga. wire or fork terminal
Battery (not included) 12 Volt, Group size U1
350 CCA, 33 amp/hr
Dimensions
Length 31.75” (80.6 cm)
Width 23.63” (60.0 cm)
Height 22.25” (56.5 cm)
Dry Weight 220 lb. (100 kg)
Gross Weight 250 lb. (114 kg)
