Panasonic WV-NP1000 - Manual (Page 57)

57
Compensate backlight
Set an area where backlight is to be compensated.
Step 1
Select "ALC" for "ALC/ELC" on the "CAMERA SETUP"
page.
→ The "ALC CONT" page will be displayed.
Step 2
Move the cursor onto "BLC" and select "ON" or "OFF".
ON: Backlight will be compensated automatically. (
→ To
step 6)
OFF: Manually set an area where backlight is to be
compensated. ( → To step 3)
Default: OFF
Step 3
Move the cursor onto "MASK SET" and press the [SET]
button.
→ The mask setup window will be displayed.
Step 4
Mask a bright area on the screen. Press the [SET] but-
ton after selecting the desired area (selected area
blinks) using the [Left], [Right], [Up] and [Down] buttons.
When the selected area is masked, horizontal stripes
and white fill will be displayed in the selected area alter-
nately. When moving to the other area, the area will be
displayed in white.
To mask the other areas, do the same procedures
above.
Select the desired masked area and press the [SET]
button.
To cancel the mask setting for all areas, press the
[Left] and [Right] buttons for 2 seconds simultane-
ously.
Step 5
After completing the mask settings, press the [SET] but-
ton for around 2 seconds.
→ The "ALC CONT" page will be displayed.
Step 6
Move the cursor onto "LEVEL" and adjust the level
using the [Left] and [Right] buttons.
Note:
To reset to the default settings, press the [Left] and
[Right] buttons simultaneously for 2 seconds or
more.
**ALC CONT**
BACK LIGHT COMP
BLC OFF
MASK SET
LEVEL ... | ...128
- +
RET TOP END
