Network Setting—DHCP 39
SmartLink 4050 Series Getting Started Guide 3 • Using the configuration menu
Figure 11. Network Settings window
Network Setting—DHCP
Click on Network Settings to display the configuration window (see figure 11 ). Select the method used to con-
nect to the Internet:
• DHCP—Select DHCP if you have cable Internet (see section “DHCP Server” for details)
• PPPoE—Select PPPoE if your ISP uses PPPoE (most DSL users choose PPPoE) (see section “DHCP
Server” for details)
• Static IP—Choose the Static IP network setting if the wide area network IP address is provided to you by
your ISP (see section
“DHCP Server” for details)
Figure 12. DHCP configuration window
DHCP Server
Dynamic host configuration protocol (DHCP) server address. This IP address information is obtained auto-
matically from your ISP.
DNS Setting
The DNS address is provided by your ISP.
