Rated Power & Load:
Power specs measured with T. Dynamics @ IO
80 W RMS into 8 ohms
100 W RMS into 4 ohms
Power @ Clipping: (typically)
(5% THD, 1 kHz, 120 V AC line)
80 W RMS into 8 ohms
100 W RMS into 4 ohms
Frequency Response:
+O, 3 dB, 60 Hz to 20 kHz, @ 65 W RMS
into 8 ohms
Hum & Noise:
Greater than 86 dB below rated power
Power Consumption:
300 W 50/60 Hz, 120 V AC, Domestic
300 W @ 60 Hz, 220-230/240 V AC, Export
PREAMP SECTION
The following specs are measured @ 1 kHz with the controls
preset as folio ws:
Push Bright, Off (Out)
Channel Select Normal (Out)
Low & High @ IO
Mid @ 0
Presence @ 0 dB
Pre 5: Post Gain @ IO
Gain 6: Thrash, Off (Out)
Normal Levels are with normal volume @ 5
Minimum Levels are with normal volume @ 10
Preamp High Gain Input:
Impedance: High-Z, 1 M ohm
Nominal Input Level: -14 dBV, 200 mV RMS
Minimum Input Level: -24 dBV, 60 mV RMS
Maximum Input Level: 0 dBV, 1 V RMS
Preamp Low Gain Input:
Impedance: High-Z, 44 K ohms
Nominal Input Level: -8 dBV, 400 mV RMS
Minimum Input Level: -18 dBV, 120 mV RMS
Maximum Input Level: 6 dBV, 2 V RMS
Effects Send:
Load Impedance: 1 K ohm or greater
Nominal Output Level: -10 dBV, 0.3 V RMS or
0 dBV, 1 V RMS if Effects Level is in
Effects Return:
Impedance: High-Z, 22 K ohms
Designed Input Level: -10 dBV, 0.3 V RMS or
0 dBV, 1 V RMS if Effects Level is in
(Switching jack provides Effects Send to Effects
Return connection when not used)
Preamp Output:
Load Impedance: 1 K ohm or greater
Nominal Output Level: 0 dBV, 1 V RMS
Power Amp Input:
Impedance: High-Z, 30 K ohms
Designed Input Level: 0 dBV, 1 V RMS
(Switching jack provides preamp output to power
amp input connection when not used)
System Hum & Noise Nominal Input Level:
(20 Hz to 20 kHz unweighted)
72 dB below rated power
Equalization:
Special low, mid, & high passive type EQ
Presence: +6 dB @ 5 kHz
Push Bright: +6 dB @ 2 kHz
Push Thrash: -20 dB notch @ 1 kHz in Lead
channel
Push Gain: Increases Lead gain
Push Resonance: +6 dB @ cabinet resonance
External Footswitch Functions:
Lead Channel Defeat (when selected with button)
Effects Loop Bypass
Dimensions & Weight:
20.0” H x 23.375” D x 11.25” D
46.5 Ibs.
T Dynamics R.O.C. Invention Patent No. 072727
~features and
Due to our for constant improvements,
specifications listed herein are subject to change without
