STEP 12:
FIGURE 12
Thank you for purchasing the Parabody 887 LAT OPTION. If unsure of proper use of equipment, call your
local Parabody distributor or call the Parabody customer service department at (800) 328-9714.
• Attach the LAT BAR (8) to the ball end of the upper CABLE (11) using one 5/16” SNAP HOOK (34) as shown in FIGURE 12.
• Attach the LOW ROW BAR (7) to the ball end of the lower CABLE (12) using one 12-LINK CHAIN (37) and two 5/16” SNAP HOOKS
(34) as shown in FIGURE 12.
• Slide two 1 X 8” GRIPS (14) on the LOW ROW BAR (7) and two 1 X 8” GRIPS (14) on the LAT BAR (8) as shown in FIGURE 12.
37
7
34
34
11
8
14
12
34
14
