2
2. Specifications
Test Pressure
Housings individually tested to 10 Bar (90 m / 300 ft.) Recommended
working pressure 60 m
Closure Design Double O-rings, Key-hole Lock
Body Material 6061 Aluminum, Acrylic
Overall Size 115 x 150 x 110 mm (LxWxH)
Total Weight Approximately 0.8 kg (Housing only)
Buoyancy (with camera) Slightly negative in salt water
Accessories
Spare main O-rings ( included)
Silicone O-ring grease ( included)
Carrying bag ( included)
Red filter (optional)
Extension arm for strobe or video light (optional)
Macro and Wide Angle lens (optional)
3. Function Controls
3.1 Buttons & Parts
(1) FLASH WINDOW
(2) FLASH EXTENSION MOUNT
(3) KEY HOLE LOCK
(4) KEY HOLE LOCK
(5) PORT
(6) ON/OFF
(7) ZOOM
(8) SHUTTER
(9) MODE DIAL
(10) REC / PLAYBACK
(11) FILM
(12) CURSOR
(13) MENU / SET
(14) DISPLAY / DELE
(15) HOUSING LID
