STEP 12:
FIGURE 12
• Attach the LAT BAR (4) to the ball end of
the LAT CABLE (11) using one SNAP LINK
(33) as shown in FIGURE 12..
4
11
33
• Slide two 1 X 8” GRIPS (15) over the ends
of the LAT BAR (4) as shown in FIGURE
12.
15
• Attach the LOW ROW BAR (3) to the ball end
of the LOW ROW CABLE (12) using two
SNAP LINKS (33) and one 12 LINK CHAIN
(35) as shown in FIGURE 13.
STEP 13:
FIGURE 13
18
3
33
12
• Slide two 1 X 8” GRIPS (15) over the ends of the
LOW ROW BAR (3) as shown in FIGURE 13.
35
13
FIGURE 14
STEP 14:
• Slide two ROLLER PADS (13) onto the KNEE
SUPPORT (6), then insert one 1-3/4” SQ. END
CAP (29) into the end of the KNEE SUPPORT (6)
as shown in FIGURE 14.
29
6
13
