SPECIFICATIONS
ELECTRICAL
Power Source:
100-230 VAC, 50/60 Hz (the included power cord is used for
120 VAC, 60 Hz)
Power Consumption:
Approximately 18 watts
Rating
ALM/CALL/MODE:
Active: “low” level, maximum current 50 mA (+5 VDC)/10 mA
(+24 VDC)
Non-active: open, maximum voltage +24 VDC
ALM/RST/REC:
Active: when terminals are short-circuited or “low” level
voltage is applied
Non-active: open
CLK:
Recording: a pulse of the frequency division ratio selected in
Rear Terminal menu
VIDEO AND AUDIO
Tape Format:
VHS, 1/2-inch width high-density video cassette tape
Television System:
525 lines, 60 field, NTSC-type color system
Video Recording System:
4 rotary heads
Luminance Signal:
Frequency modulation recording
Color Signal:
Low frequency conversion, sub-carrier phase shift recording
Audio Track:
1 track
Tape Speed and
Recording Time:
Refer to Table I
Fast Forward/Rewind Time:
Approximately 160 seconds with T-160 tape
Horizontal Resolution:
More than 330 lines (black and white)
More than 240 lines (color)
Audio Frequency
Response:
70 Hz - 4 kHz (8H mode)
Signal-to-Noise Ratio:
Video: better than 42 dB
Audio: better than 43 dB
Input:
Video: 1.0 Vp-p, 75 ohms, BNC plug
Audio: 308 mV (rms), 50 ohms, RCA plug
Output:
Video: 1.0 Vp-p, 75 ohms, BNC plug
Audio: 388 mV (rms), 1 ohm, RCA plug
Battery Backup:
Lasts 31 days
