R11 Series Drive Command Reference Manual Version 1.00
4.22 READ TRACK/RZONE INFORMATION Command
The Track/RZone Information data is defined as shown in following list.
Table 31 – Track/RZone Information returned
Bit
Byte
7 6 5 4 3 2 1 0
0 (MSB)
1
Track/RZone Information length
(LSB)
2 Track/RZone Number (LSB)
3 Session/Border Number (LSB)
4 Reserved
5 LJS
Damage Copy Track Mode
6 RT Blank
Packet/I
nc
FP Data Mode
7 Reserved LRA_V NWA_V
8 (MSB)
9
10
11
Track/RZone Start Address
(LSB)
12 (MSB)
13
14
15
Next Writable Address
(LSB)
16 (MSB)
17
18
19
Free Blocks
(LSB)
20 (MSB)
21
22
23
Fixed Packet Size/
Blocking Factor
(LSB)
24 (MSB)
25
26
27
Track/RZone Size
(LSB)
28 (MSB)
29
30
31
Last recorded Address
(LSB)
32 Track/RZone Number (MSB)
33 Session/Border Number (MSB)
34 Reserved
35 Reserved
36 (MSB)
37
38
39
Read Compatibility LBA
(LSB)
40 (MSB)
41
42
43
Next Layer Jump Address
(LSB)
44 (MSB)
45
46
47
Last Layer Jump Address
(LSB)
If the Layer Jump Recording is supported, the size of Track/RZone Information returned is 48 bytes and
the Track/RZone Information length field is set to 2Eh.
Page 48
