AUXILIARY OUTPUTS
Number of Outputs:
3
Connector Type:
12-pin screw terminal
Contact Configuration
F1:
Form C, 0.5 A at 125 VAC maximum
F2 and F3:
Open collector, 32 VDC at 25 mA maximum
POWER SUPPLY
Input Voltage:
120 VAC, 50/60 Hz or 230 VAC, 50 Hz
Power Consumption:
10 watts
Ambient Operating
Temperature:
20° to 120°F (-7° to 49°C)
Humidity:
10–90% noncondensing
PHYSICAL SPECIFICATIONS
Dimensions:
17.0 (W) x 10.5 (D) x 3.5 (H) inches
(43.18 x 26.67 x 8.89 cm)
Weight
CM6700-MXB2:
9.39 lb (4.26 kg)
CM6700-MXB2-X:
9.47 lb (4.30 kg)
CM6700-MXB4:
10.15 lb (4.61 kg)
CM6700-MXB4-X:
10.06 lb (4.56 kg)
Rating:
Meets NEMA Type 1 standard
(Design and product specifications subject to change without notice.)
