POLK AUDIO
5601 METRO DRIVE
BALTIMORE, MD 21215
WWW.POLKAUDIO.COM
CUSTOMER SERVICE:
800-377-7655 (USA & CANADA)
410-358-3600 (WORLDWIDE)
COPYRIGHT© APRIL 2008
ALL RIGHTS RESERVED.
We’re fanatics when it comes to providing you useful, accurate information that can help you evaluate our products. But as we all know, we live in an imperfect world.
At least some of us do. That’s why performance specifications and product dimensions are subject to change without notice. For the most current specifications see
our website, www.polkaudio.com/home.
Polk Audio is a Directed Electronics company which trades on NASDAQ under the symbol DEIX. Investor information can be found at http://investor.directed.com.
Polk Audio, Polk, PowerPort, Dynamic Balance, F/X, Atrium, Big Speaker Sound Without The Big Speaker, High Velocity Compression Drive, Acoustic Resonance Control, ARC
Port, Casket Basket, I-Sonic, SurroundBar & SDA are registered trademarks of Britannia Investment Corporation used under license by Polk Audio, Incorporated. Polk Audio
Designs & miDock are trademarks of Britannia Investment Corporation used under license by Polk Audio, Incorporated.
CUSTOM INSTALL
LOUDSPEAKERS
TC265i TC65i TC625i
Driver Complement 1 - 6 1/2" (16.51cm) Dynamic Balance 1 - 6 1/2" (16.51cm) Dynamic Balance 1 - 6 1/2" (16.51cm) Dynamic Balance
midrange driver, mid/bass driver, polymer composite cone driver,
1 - 6 1/2" (16.51cm) Dynamic Balance 1 - 1" (2.5cm) cloth dome/ball 1 - 3/4" (1.91cm) silk dome tweeter
woofer driver, & socket tweeter
1 - 1" (2.5cm) Silk Polymer composite
dome/ball & socket tweeter
Shape rectangle rectangle rectangle
Frequency Response: Overall / -3dB Limits 30Hz - 27kHz / 45Hz - 25kHz 32Hz - 27kHz / 50Hz - 25kHz 35Hz - 25kHz / 50Hz - 23kHz
Impedance compatible with 8 Ohms compatible with 8 Ohms compatible with 8 Ohms
Recommended Amplification 10 - 200 Watts / channel 10 - 125 Watts / channel 20 - 100 Watts / channel
Efficiency 91dB 90dB 89dB
Available Finish matte white (paintable) matte white (paintable) matte white (paintable)
Product Weight / Shipping Weight 7.1 lbs each / 9.70 lbs each 3.85 lbs each / 5.65 lbs each 3.45 lbs each / 5 lbs each
3.2 kg each / 4.4 kg each 1.85 kg each / 2.56 kg each 1.56 kg each / 2.27 kg each
Overall Dimensions (Depth measured from 20 13/16" H x 8 1/2" W x 3 1/2"D 14 5/16" H x 8 1/2" W x 3 3/16"D 14 5/16" H x 8 1/2" W x 3 3/16"D
the deepest component to the back of the baffle) (52.86cm H x 21.59cm W x 8.89cm D) (36.35cm H x 21.59cm W x 8.096cm D) (36.35cm H x 21.59cm W x 8.1cm D)
Depth Assuming 1/2" Drywall 3" (7.6cm) 2 11/16" (6.83cm) 2 11/16" (6.83cm)
Cutout Dimensions 19 3/16" H x 7 1/4" W 12 3/4" H x 7 1/4" W 12 3/4" H x 7 1/4" W
(48.7cm H x 18.4cm W) (32.38cm H x 18.41cm W) (32.38cm H x 18.41cm W)
Features PowerPort ® , User Controls PowerPort ® , User Controls Aimable Tweeter, Rotating Cam Install
CUSTOM INSTALL
LOUDSPEAKERS
TC80i TC60i TC620i
Driver Complement 1 - 8" (20.3cm) Dynamic Balance 1 - 6 1/2" (16.5cm) Dynamic Balance 1 - 6 1/2" (16.5cm) Dynamic Balance
mid/bass driver, mid/bass driver, polymer composite cone driver,
1 - 1" (2.5cm) cloth dome/ball & socket tweeter 1 - 1" (2.5cm) cloth dome/ball & socket tweeter 1 - 3/4" (1.91cm) silk dome tweeter
Shape round round round
Frequency Response: Overall / -3dB Limits 30Hz - 27kHz / 45Hz - 25kHz 32Hz - 27kHz / 50Hz - 25kHz 35Hz - 25kHz / 50Hz - 23kHz
Impedance compatible with 8 Ohmsa compatible with 8 Ohms compatible with 8 Ohms
Recommended Amplification 10 - 125 Watts / channel 10 - 125 Watts / channel 20 - 100 Watts / channel
Efficiency 90dB 90dB 89dB
Available Finish matte white (paintable) matte white (paintable) matte white (paintable)
Product Weight / Shipping Weight 3.5 lbs each / 5.35 lbs each 3.5 lbs each / 5.15 lbs each 3.25 lbs each / 5 lbs each
1.6 kg each / 2.43 kg each 1.6 kg each / 2.34 kg each 1.47 kg each / 2.27 kg each
Overall Dimensions 10 5/8" Diameter x 5 5/16" Depth 9 5/16" Diameter x 5 1/16" Depth 9 5/16" Diameter x 4 1/8" Depth
(26.99cm Diameter x 13.5cm Depth) (23.65cm Diameter x 12.9cm Depth) (23.65cm Diameter x 10.48cm Depth)
Depth Assuming 1/2" Drywall 4 13/16" (12.2cm) 4 9/16" (11.6cm) 3 5/8" (9.21cm)
Cutout Dimensions 9 3/8" Diameter (23.81cm) 8 3/16" Diameter (20.8cm) 8 3/16" Diameter (20.8cm)
Features 15˚ Driver Offset, User Controls 15˚ Driver Offset, User Controls Aimable Tweeter, Rotating Cam Install
TCi SERIES LOUDSPEAKERS PRODUCT SPECIFICATIONS
