Page 25
16
97705183 A
User Manual
Appendix C
SCSI Device Address
Jukebox Connector SCSI ID
SCSI Drive
JP1 or SW3
JP2 or SW2
JP3 or SW1
Address
0
OFF
OFF
OFF
1
OFF
OFF
ON
2
OFF
ON
OFF
3
OFF
ON
ON
4
ON
OFF
OFF
5
ON
OFF
ON
6
ON
ON
OFF
7
ON
ON
ON
Drives are set up to ID1 as default
Default Jumpers on external and internal units
Jumper/Switch
internal
external
JP1/SW3
N/C
OFF
JP2/SW2
N/C
OFF
JP3/SW1
Fitted
ON
JP4
N/C
N/C
JP5
N/C
N/C
JP6
N/C
N/C
JP7/SW4
Fitted
ON
JP8
N/C
N/C
JP9/SW5
Fitted
ON
JP10/SW6
N/C
OFF
JP11
N/C
N/C
JP12
Fitted
Fitted
