PoGo Products Radio YourWay - Manual (Page 36)

Record Time 32Mbyte : 135Min/270Min
Mode ADPCM 32Kbps/16Kbps
File VOICE : 99 / MP3
FM Record FM band, Stereo (76MHz-108MHz) (USA 87.5-108)
AM Record 530kHz – 1710kHz
Timer Record Date / Daily / Weekly
Mic Built-in Mic / Line (external Mic)
Record Device Built-in Flash Memory(32MB)/EXT(MMC/SD CARD 256)
S/N 45db (62db input 1kHz , speaker output 50mW )
Distortion 3%±0.2 (62db input 1kHz , speaker output 50mW : HQ mode )
Freq,Response 400Hz-3.2kHz(-6db)
Output Power Max 5mW(stereo earphone 16ohm)
VOICE
RECORD/
PLAY
Repeat Play One messages repeat/Cont. messages repeat / A-B repeat
S/N 45db at 1mv 98.1MHz
Distortion 0.8%(max) at 1mv 98.1MHz ∆f=22.5kHz
Freq,Response 350Hz±30Hz,3kHz±0.25kHz(150Hz-2.5kHz,60dbuV)
Sensitivity 5uV at S/N=26db
Frequency
Cover Range
World wide : 76 - 108MHz USA 87.5-108
FM
RADIO
(Stereo)
Preset Mode 10 Radio station
S/N 35db
Distortion 3%
Freq,Response 150Hz – 1.5kHz at 0db
Sensitivity 68dbuV at 1000kHz
Frequency
Cover Range
531kHz – 1629kHz
AM
RADIO
Preset Mode 10 Radio station
Bit/Rate 32Kbps-320Kbps(MPEG 1/2 LAYER 3)
S/N 85db up(1kHz input 0db)
Distortion 0.3%±0.05 (1kHz input 0db)
Freq,Response 20Hz-20kHz
Earphone Max 5mW(16ohm)
EQ EQ : NORMAL, ROCK, POP, CLASSIC, LIVE
MP3
Repeat Play ALL1/ALL/1/1ALL/A-B
Communication USB 1.1
System CPU200MHz more than, RAM 64MB more than, 20MB of free space
OS Windows 98, 2000, ME, XP
Sound Card Sound Blaster 16 compatible
PC
Interface
Display 640X480 more than
Ext Line in ∮3.5 plug-in power microphone(mini plug/stereo) IMP less than 3KΩ
Earphone ∮3.5 earphone(mini plug/stereo) IMP less than 16Ω
IN/OUT
JACK
DC JACK HOLE : ∮2.75, Dia : ∮0.65
