Menu operation section – Panasonic AJ-P2C002SG User Manual
Page 23
23
Parts and their Functions: Menu Operation Section
P
ar
ts
and
thei
r F
unc
tions
1. MENU button
Used to turn on/off the menu.
2. Jog dial button
With the menu open, this button is used to navigate
through menu pages, select options and specify values.
For directions on manipulating the menu, see [Menu
Configuration] (page 161).
3. SD memory card insertion slot
An SD memory card (optional) is inserted here. It is
used when writing or saving menu data or lens files on
an SD memory card.
4. Busy (operation mode display) lamp
This lamp indicates the active status of the SD memory
card.
It stays illuminated when the card is active.
Note
While the lamp is on, do not insert or remove the card.
5. SHOT MARKER/MENU CANCEL button
Undoes any changes to the menu option settings if
pressed during the changes.
Menu Operation Section
4
3
1
2
5
AJ-HPX2700G-VQT1V27_eng.book 23 ページ ２００８年９月２日 火曜日 午後５時４３分
