Patton electronic 3088A User Manual
Page 25
Introduction
25
Model 3088A Series User Manual
2 • Configuration
OFF
ON
OFF
OFF
OFF
OFF
ON
2240
OFF
ON
OFF
OFF
OFF
ON
OFF
2304
OFF
ON
OFF
OFF
OFF
ON
ON
2368
OFF
ON
OFF
OFF
ON
OFF
OFF
2432
OFF
ON
OFF
OFF
ON
OFF
ON
2496
OFF
ON
OFF
OFF
ON
ON
OFF
2560
OFF
ON
OFF
OFF
ON
ON
ON
2624
OFF
ON
OFF
ON
OFF
OFF
OFF
2688
OFF
ON
OFF
ON
OFF
OFF
ON
2752
OFF
ON
OFF
ON
OFF
ON
OFF
2816
OFF
ON
OFF
ON
OFF
ON
ON
2880
OFF
ON
OFF
ON
ON
OFF
OFF
2944
OFF
ON
OFF
ON
ON
OFF
ON
3008
OFF
ON
OFF
ON
ON
ON
OFF
3072
OFF
ON
OFF
ON
ON
ON
ON
3136
OFF
ON
ON
OFF
OFF
OFF
OFF
3200
OFF
ON
ON
OFF
OFF
OFF
ON
3264
OFF
ON
ON
OFF
OFF
ON
OFF
3328
OFF
ON
ON
OFF
OFF
ON
ON
3392
OFF
ON
ON
OFF
ON
OFF
OFF
3456
OFF
ON
ON
OFF
ON
OFF
ON
3520
OFF
ON
ON
OFF
ON
ON
OFF
3584
OFF
ON
ON
OFF
ON
ON
ON
3648
OFF
ON
ON
ON
OFF
OFF
OFF
3712
OFF
ON
ON
ON
OFF
OFF
ON
3776
OFF
ON
ON
ON
OFF
ON
OFF
3840
OFF
ON
ON
ON
OFF
ON
ON
3904
OFF
ON
ON
ON
ON
OFF
OFF
3968
OFF
ON
ON
ON
ON
OFF
ON
4032
OFF
ON
ON
ON
ON
ON
OFF
4096
OFF
ON
ON
ON
ON
ON
ON
4160
ON
OFF
OFF
OFF
OFF
OFF
OFF
4224
ON
OFF
OFF
OFF
OFF
OFF
ON
4288
ON
OFF
OFF
OFF
OFF
ON
OFF
4352
ON
OFF
OFF
OFF
OFF
ON
ON
4416
ON
OFF
OFF
OFF
ON
OFF
OFF
4480
ON
OFF
OFF
OFF
ON
OFF
ON
4544
ON
OFF
OFF
OFF
ON
ON
OFF
4608
Table 5. S4-2 through S4-8 Data Rate DIP switch settings (Continued)
S4-2
S4-3
S4-4
S4-5
S4-6
S4-7
S4-8 Data Rate (kbps)
