Specifications
X-Monitor owner’s manual
+0/-1dB 20Hz–20kHz ref 1kHz —any input to any output
any output <.01% THD 20Hz–20kHz @ +15dBu out
mic ein better-than -128dBu 20Hz–20kHz —150ohm source, 60dB gain
channel mute >80dB channel routing >80dB
channel fader attenuation >90dB aux send attenuation >75dB
< +/- 30 degrees, 20Hz–20kHz —mic-in to main-out
mic-in XLR 4k ohm balanced—max voltage gain to group balanced out = 98dB
line-in TRS >10k ohms balanced
left/right/mono—group, aux, matrix—monitor-out all 100 ohms balanced
headphones to drive > eight-ohms
send 50 ohms ground-compensated on TRS jack
return >10k ohms balanced on TRS jack
+4dBu max level +26dBu balanced into >1k ohms
high freq +/- 15dB shelf at 12kHz
hi-mid freq +/- 15dB bell freq range 400Hz–8kHz , Q=1.5
low-mid freq +/- 15dB bell freq range 80Hz–2kHz , Q=1.5
low freq +/- 15dB bell-boost /shelf-cut freq center 80Hz , Q=.7 on boost
high-pass filter -12dB/octave freq range 20Hz–400Hz
separate on-switches for eq and high-pass filter
five-band eq on all main outputs high-pass filter: -12dB/octave freq range 20Hz–400Hz
separate on-switches for eq and high-pass filter
five-segment LED ladder with VU-type response—displays pre-fader signal level
top red-LED warns of impending overload anywhere within the channel
fourteen mechanical VU-type meters with LED illumination
twelve-meters showing group-out
two dedicated solo-meters
pink-noise generator can feed the talk-back section
chassis is powder-coated 14-gauge galvanized steel with internal-bracing
modules are powder-coated 18-gauge galvanized steel with baked-epoxy screening
see dimension-drawing
five-years
frequency response
THD
noise
crosstalk
phase shift
inputs
outputs
insert
nominal output level
input channel eq
output features
channel metering
master metering
signal generator
construction
dimensions and weights
warranty
