Connections
(continued)
Step 6: Connecting the
power cord
O
O
COAXIAL
DIGITAL IN
BWOOFER
TV
~ AC
MAINS
TO DVD
SYSTEM
FRONT
LEFT
CENTER FRONT
RIGHT
REAR
LEFT
REAR
RIGHT
DVD system
After everything is connected
properly, plug the AC power cord
into the power outlet.
The ECO POWER LED on the DVD
system and AV Subwoofer LED will light
up. Never make or change any
connections with the power switched on.
Helpful Hint:
– Refer to the type plate on the rear or
bottom of the product for identification and
supply ratings.
