21
Compatibility Modes
Mode Resolution
V. Frequency
(Hz)
H. Frequency
(kHz)
IBM VGA 720 x 400 70 31.5
IBM VGA 640 x 480 60 31.5
VESA VGA 640 x 480 72 37.9
VESA VGA 640 x 480 75 37.5
VESA SVGA 800 x 600 56 35.2
VESA SVGA 800 x 600 60 37.9
VESA SVGA 800 x 600 72 48.1
VESA SVGA 800 x 600 75 46.9
VESA XGA 1024 x 768 60 48.4
VESA XGA 1024 x 768 70 56.5
VESA XGA 1024 x 768 75 60.0
VESA SXGA 1280X1024 60 64.0
VESA SXGA 1280X1024 75 80.0
1280X960 60 108
1152X864 75 108
Apple Mac II
(PT1700MX/PT1701MX
only)
640 x 480 67 35.0
Apple Mac
(PT1700MX/PT1701MX
only)
832 x 624 75 49.7
